BCS BCS-F-ADE01 Inyector PoE Gigabit, 15,4 W, IEEE 802.3af

The BCS BCS-F-ADE01 is a reliable Gigabit Power over Ethernet (PoE) injector designed to deliver both data and power over a single Ethernet cable. Compliant with IEEE 802.3af standard, it provides up to 15.4W of power to PoE-enabled devices such as IP cameras, wireless access points, and VoIP phones. With its compact plastic housing, it is suitable for desktop or wall-mount installation.

Advantages

Simplifies network setup by eliminating the need for separate power cables for each device. Supports Gigabit Ethernet speeds (10/100/1000 Mbps) ensuring high data throughput. Features overload, short circuit, and overvoltage protection for safe operation.

Suitable for

• IP cameras
• Wireless access points
• VoIP phones
• Any IEEE 802.3af compliant PoE device

Key specifications

• PoE Standard: IEEE 802.3af
• PoE Output Power: 15.4 W
• PoE Output Voltage: 48 V DC
• PoE Output Current: 0.32 A
• Data Rate: Gigabit Ethernet (10/100/1000 Mbps)
• Ethernet Ports: 2 (1x Data In, 1x Data + Power Out)
• Input Voltage: 100-240 V AC
• Input Frequency: 50/60 Hz
• Power Pins: 1/2 (+), 3/6 (-) (Mode A)
• LED Indicators: Power
• Operating Temperature: -10°C to 45°C
• Storage Temperature: -20°C to 70°C
• Operating Humidity: 5% to 90% RH (non-condensing)
• Protection Features: Overload, Short Circuit, Overvoltage
• Housing Material: Plastic
• Mounting Type: Desktop / Wall-mount
• Certifications: CE, FCC

Recommendations

For optimal performance, use with standard Cat5e or higher Ethernet cables. Ensure the connected device is PoE compatible and does not exceed 15.4W power consumption.
