BlueOptics FTLF1519P1xNL Transceptor SFP compatible BO05C156C0D - 1,25 Gbps 1550nm 10km LC SMF

The BlueOptics FTLF1519P1xNL compatible SFP BO05C156C0D is a high-performance, cost-effective optical transceiver designed for Gigabit Ethernet and Fibre Channel applications. This SFP module is fully compliant with the IEEE 802.3z 1000BASE-LX standard and is a direct replacement for the Finisar FTLF1519P1xNL, ensuring seamless integration into existing network infrastructure.

Advantages

This transceiver offers reliable, high-speed data transmission over single-mode fiber at distances up to 10 km. With support for Digital Diagnostic Monitoring (DDM/DOM), network administrators can monitor real-time parameters such as temperature, voltage, and optical power levels for proactive maintenance. The hot-pluggable SFP form factor allows for easy installation and replacement without disrupting network operations.

Suitable for

• Data center interconnects
• Enterprise networking
• Telecommunications
• Metropolitan area networks (MANs)
• Gigabit Ethernet and Fibre Channel deployments

Key specifications

• Form Factor: SFP
• Data Rate: 1.25 Gbps
• Wavelength: 1550 nm
• Max Reach: 10 km (6.2 miles)
• Fiber Type: Single-Mode Fiber (SMF)
• Connector: LC Duplex
• Transmitter: DFB Laser
• Receiver: PIN Photo Detector
• DDM/DOM: Yes
• Operating Temperature: 0°C to 70°C (32°F to 158°F)
• Power Consumption: < 1.0 W
• Voltage: 3.3 V
• Hot-Pluggable: Yes
• Certifications: CE, FCC, RoHS

Recommendations

For optimal performance, use with single-mode fiber optic cables terminated with LC connectors. Ensure compatibility with your network equipment's SFP slot. This module is MSA compliant and tested for interoperability with major brands.
