Bopla carcasa universal 110 x 188 x 70 gris claro E 450 05450000

The Bopla E 450 universal enclosure stands out with its robust ABS construction and light grey RAL 7035 finish, offering a clean, professional look for a wide range of electronic applications. Its generous internal dimensions of 110 x 188 x 70 mm provide ample space for PCBs and components, while the IP65 protection class ensures reliable sealing against dust and water jets.

Highlights

• Durable ABS plastic body in light grey (RAL 7035)
• IP65 rated for dust-tight and water-jet protection
• External dimensions: 188 mm length, 110 mm width, 70 mm height
• Screw-on lid with stainless steel screws and polyurethane gasket
• Impact resistance IK07 for demanding environments
• Flammability rating UL 94 V-0
• Internal mounting bosses for PCBs and components
• Wall mounting possible
• Operating temperature range: -40°C to +80°C

In daily use

This enclosure is well-suited for housing electronics in industrial, automation, and outdoor settings where protection from moisture and mechanical impact is required. The light grey colour blends seamlessly into most control cabinets and machinery. The screw-on lid with stainless steel hardware ensures a secure fit, while the PU gasket maintains the seal over time.

Full specifications

• Enclosure Type: Universal Enclosure
• Material: ABS Plastic
• Colour: Light Grey (RAL 7035)
• Protection Class: IP65
• External Length: 188 mm
• External Width: 110 mm
• External Height: 70 mm
• Lid Type: Screw-on
• Lid Screw Material: Stainless Steel
• Gasket Material: Polyurethane (PU)
• Operating Temperature Range: -40°C to +80°C
• Flammability Rating: UL 94 V-0
• Impact Resistance: IK07
• Mounting Options: Internal mounting bosses for PCBs/components, Wall mounting
• Number of Pieces: 1
• RoHS Compliant: Yes

Final note

A reliable enclosure for projects that demand protection and durability, with a neutral light grey aesthetic that fits any environment.
