Bopla carcasa universal 160 x 160 x 90 aluminio gris plata (RAL 7001) A 125 01125000.H

This Bopla universal enclosure in size 160 x 160 x 90 mm is crafted from aluminium with a silver grey powder-coated finish (RAL 7001), offering a robust housing for electronics in industrial and outdoor settings. Its IP66 protection and neoprene gasket ensure reliable sealing against dust and water, while stainless steel lid screws provide secure closure.

Highlights

• Aluminium body with powder-coated silver grey surface (RAL 7001)
• IP66 protection rating for demanding environments
• Neoprene gasket and stainless steel lid screws included
• External dimensions: 160 mm length, 160 mm width, 90 mm height
• Operating temperature range: -40 to +100 °C

In daily use

The enclosure's 3 mm wall thickness and surface-mount design make it suitable for housing control electronics, sensors, or connection interfaces. The included gasket and screws simplify assembly, and the aluminium construction provides durability without excessive weight.

Full specifications

• Enclosure type: Universal enclosure
• Material: Aluminium
• External length: 160 mm
• External width: 160 mm
• External height: 90 mm
• Colour: Silver grey (RAL 7001)
• Protection class: IP66
• Lid fastening: Stainless steel screws
• Gasket material: Neoprene
• Surface finish: Powder coated
• Mounting type: Surface mount
• Operating temperature range: -40 to +100 °C
• Wall thickness (nominal): 3 mm
• Internal length (approx.): 154 mm
• Internal width (approx.): 154 mm
• Internal height (approx.): 87 mm
• Flammability rating: Non-flammable
• RoHS compliant: Yes
• Included components: Enclosure base, lid, lid screws, gasket

Final note

A reliable aluminium enclosure with IP66 sealing, ideal for protecting electronics in harsh conditions.
