Bopla carcasa universal 58 x 64 x 34 mm aluminio gris plata (RAL 7001) A 101 01101000.MT2

Sealed to IP65 and machined from aluminium, this 58 x 64 x 34 mm enclosure shrugs off dust, water jets and temperatures from -40°C to +100°C. The silver-grey RAL 7001 powder coat and stainless steel lid screws make it a rugged housing for industrial electronics.

Overview

The Bopla A 101 universal enclosure provides a compact, robust shell for control systems, measurement technology and industrial electronics. Its aluminium body and neoprene gasket deliver reliable protection in harsh environments. Integrated guide grooves allow direct PCB mounting, simplifying assembly.

What stands out

• IP65 protection against dust and water jets
• Wide operating temperature range: -40°C to +100°C
• Powder-coated aluminium with silver-grey RAL 7001 finish
• Four stainless steel lid screws for secure closure
• Neoprene gasket for a tight seal
• Integrated guide grooves for PCB mounting

Technical details

• External dimensions: 58 mm (W) x 64 mm (D) x 34 mm (H)
• Material: Aluminium
• Colour: Silver-grey (RAL 7001)
• Protection class: IP65
• Lid fastening: 4x stainless steel screws
• Temperature range: -40°C to +100°C
• Surface finish: Powder coated
• Gasket material: Neoprene
• Internal mounting: Integrated guide grooves for PCBs
• Application area: Industrial electronics, control systems, measurement technology

Our verdict

A dependable, no-nonsense aluminium enclosure for demanding industrial environments. The IP65 rating and wide temperature tolerance make it a solid choice for protecting sensitive electronics.
