Busch-Jaeger Toma SCHUKO doble con tapa abatible roja, horizontal, 16 A, empotrable

Double SCHUKO socket outlet with a red hinged cover, designed for horizontal flush-mounted installation. The red cover clearly identifies special circuits such as emergency power or cleaning power, preventing accidental disconnection.

Advantages

The hinged cover protects the sockets from dust and contamination when not in use, while the red colour provides instant visual identification. The robust thermoplastic housing ensures durability in indoor environments.

Suitable for

• Marking dedicated circuits (emergency power, cleaning power)
• Indoor flush-mounted installations
• Residential and commercial applications requiring clear circuit identification

Key specifications

• Socket type: SCHUKO (Type F)
• Number of sockets: 2 (horizontal arrangement)
• Rated voltage: 250 V AC
• Rated current: 16 A
• Mounting type: Flush-mounted
• Connection: Screw terminals, up to 2 x 2.5 mm²
• Material: Thermoplastic
• Colour: Red (RAL 3003)
• Design line: Busch-Duro 2000® SI
• Halogen-free

Recommendations

Ideal for installations where specific circuits must be visually distinguishable, such as in hospitals, workshops, or data centres. Pair with matching frames from the Busch-Duro 2000® SI range for a cohesive look.
