Caja de PC Akasa Turing TN Ultra Small Form Factor Negra

The Akasa Turing TN Ultra Small Form Factor Black is a compact, fanless aluminium case designed for Intel® 11th Generation NUC (Tiger Canyon) systems. It supports an external power supply and one 2.5" drive, and includes an internal M.2 SSD heatsink to reduce storage temperature and sustain performance. With a slim black finish and extruded fin design, the case is built for durability and space-constrained environments while offering connector openings for up to four 4K displays.

Advantages

The all-aluminium body acts as an effective passive heatsink, transferring CPU and GPU heat away through thermal modules to the case exterior for reliable thermal performance without fans. An internal M.2 SSD heatsink helps lower NAND temperature and maintain SSD throughput. The symmetrical extruded fins and classical-inspired panels combine functional cooling with a durable, modern aesthetic suitable for both home and business use.

Suitable for

• Compact desktop builds using Intel® 11th Gen NUC (Tiger Canyon)
• Home theatre PCs and media players
• Digital signage and retail displays
• Security and surveillance systems with multiple displays

Key specifications

• Compatible Intel® NUC models: NUC11TNKi3 / NUC11TNHi3 / NUC11TNBi3; NUC11TNKi5 / NUC11TNHi5 / NUC11TNBi5; NUC11TNKv5 / NUC11TNHv5 / NUC11TNBv5; NUC11TNKi7 / NUC11TNHi7 / NUC11TNBi7; NUC11TNKv7 / NUC11TNHv7 / NUC11TNBv7
• Form factor: Ultra Small Form Factor (USFF)
• Material: Aluminium
• Drive bays: 1 × 2.5" HDD/SSD
• Power supply: external (not included)
• Colour: Black
• MPN: A-NUC68-M1B
• EAN: 4710679551036

How to use

Install the compatible Intel® 11th Gen NUC motherboard into the case following the manufacturer's NUC installation instructions. Mount a 2.5" HDD or SSD in the dedicated bay if required and attach the M.2 SSD to the onboard slot so that it contacts the internal heatsink. Connect the external power supply to the case and route display and peripheral cables through the provided connector openings. Place the case in a ventilated location to allow passive heat dissipation through the aluminium fins.

Recommendations

Ensure proper contact between the M.2 SSD and the internal heatsink during installation; use compatible NUC models listed in the specifications. Keep the unit free from dust buildup and position it with clearance around the fins to maintain optimal passive cooling performance.
