Carcasa universal BOPLA aluminio gris plata (RAL 7001) 50 x 45 x 30 A 100 1 ud. (01100000.MT1)

IP66-rated aluminium enclosure in silver-grey (RAL 7001) with external dimensions 50 x 45 x 30 mm. The screw-on lid and integrated gasket provide reliable protection for industrial electronics.

Overview

The BOPLA A 100 series universal enclosure is constructed from aluminium with a silver-grey powder coating (RAL 7001). It measures 50 mm in length, 45 mm in width, and 30 mm in height, offering a compact housing for electronic components. The enclosure features a screw-on lid and a gasket, achieving an IP66 ingress protection rating. Internal mounting bosses allow secure installation of PCBs or components.

What stands out

• IP66 protection against dust and water jets
• Aluminium construction for durability and heat dissipation
• Screw-on lid with gasket for secure sealing
• Internal mounting bosses for easy component installation
• Silver-grey RAL 7001 finish

Technical details

• Enclosure type: Universal enclosure
• Material: Aluminium
• Colour: Silver-grey (RAL 7001)
• External dimensions: 50 x 45 x 30 mm (L x W x H)
• Series: BOPLA A 100
• Ingress protection: IP66
• Lid fastening: Screw-on
• Gasket: Yes
• Internal mounting: Mounting bosses for components/PCBs
• Unit quantity: 1 piece

Our verdict

A compact, IP66-rated aluminium enclosure ideal for industrial and general-purpose electronics requiring robust protection.
