Controlador LED MEAN WELL ELG-200-24-3Y potencia de salida 200 W IP20

The MEAN WELL ELG-200-24-3Y is an AC-DC single-output LED driver combining constant voltage and constant current (CV+CC) control with active power factor correction (PFC). It accepts a wide AC input range and delivers 24 V DC at up to 8.4 A, with a fixed constant-current feature and cable output. The unit is designed for general LED lighting applications and has an IP20 enclosure rating.

Advantages

The driver provides both constant-voltage and constant-current regulation for stable LED operation and includes PFC to improve input power quality. Its wide input voltage range allows use on various mains supplies, while the cable output and fixed CC output simplify installation and wiring. The compact housing dimensions make it suitable for installations with limited space.

Suitable for

• Indoor LED lighting fixtures
• Linear LED strips and modules requiring 24 V DC
• Retrofit and new-build general lighting projects

Key specifications

• Output voltage: 24 V DC
• Maximum output current: 8.4 A
• Output power: 200 W
• Input voltage range: 100–305 V AC
• Control type: CV + CC with fixed constant-current feature
• Power factor correction (PFC): integrated
• Enclosure protection rating: IP20
• Output: cable-mounted
• Dimensions (W×D×H): 71 × 244 × 37.5 mm

How to use

Connect the driver to a suitable AC supply within the specified input voltage range using the three-wire input. Connect the 24 V DC cable output to the LED load, observing correct polarity. Ensure the total LED load does not exceed 200 W or the maximum output current of 8.4 A. Install the driver in a dry, ventilated location consistent with its IP20 rating and secure it according to local electrical regulations.

Recommendations

For reliable long-term operation, use the driver indoors where it is protected from moisture and excessive dust, avoid enclosing it in completely sealed compartments without ventilation, and ensure adequate heat dissipation around the unit. Verify compatibility of LED modules with 24 V CV operation and the fixed CC feature before installation.
