DELTA FX-RJ45-52 Keystone Jack Cat.5e UTP RJ45 hembra 8P8C T568A/B negro

With gold-plated contacts rated for over 750 insertion cycles, the DELTA FX-RJ45-52 keystone jack delivers dependable Cat.5e performance in a compact, tool-free-friendly form factor. This unshielded RJ45 module terminates 22–26 AWG solid or stranded conductors via standard 110-style IDC punch-down, supporting both T568A and T568B wiring schemes for maximum installation flexibility.

Overview

The DELTA FX-RJ45-52 is a Category 5e keystone jack designed for structured cabling systems in commercial and residential environments. It fits any standard keystone wall plate, patch panel, or surface-mount box with a 19.2 x 14.9 mm opening. The black ABS housing meets UL 94V-0 flammability standards, ensuring safety in plenum and riser spaces. The module supports Gigabit Ethernet (1000BASE-T) and all lower-speed applications, making it a versatile choice for voice, data, and video distribution.

What stands out

• Gold-plated contacts (50 micro-inches) resist corrosion and maintain signal integrity over repeated mating cycles.
• Dual wiring standard compatibility (T568A/B) with clear colour-coded labelling for error-free termination.
• IDC terminals accept 22–26 AWG solid or stranded wire, allowing use with both horizontal and patch cabling.
• Robust ABS housing with UL 94V-0 rating provides durability and fire resistance.
• Wide operating temperature range (-10°C to 60°C) suits most indoor installations.

Technical details

• Connector type: RJ45 female, 8P8C (8 positions, 8 contacts)
• Category rating: Cat.5e
• Shielding: UTP (unshielded)
• Wiring standard: T568A/T568B
• Termination: 110-style IDC punch-down
• Conductor gauge: 22–26 AWG solid or stranded
• Contact plating: 50 micro-inches gold
• Housing material: ABS, UL 94V-0
• Operating temperature: -10°C to 60°C
• Storage temperature: -40°C to 70°C
• Insertion durability: ≥750 cycles
• IDC re-terminations: ≥200 cycles
• Certifications: RoHS, CE

Our verdict

A reliable and versatile Cat.5e keystone jack that combines durable gold-plated contacts, dual wiring compatibility, and a fire-resistant housing—ideal for any structured cabling project.
