DELTA PUH-3PK Caja de derivación empotrable superficie blanca IP20

The DELTA PUH-3PK junction box is a high-quality surface-mounted enclosure designed for indoor electrical installations. Made from durable polypropylene (PP), it offers excellent halogen-free performance and complies with CE and RoHS standards. Ideal for connecting and protecting electrical cables, this empty box features 8 knock-out cable entries and a snap-on lid for quick and secure closure.

Advantages

Halogen-free material ensures safety in case of fire. Snap-on lid allows tool-free access. Compact design saves space. Rated for up to 400V and 16A, suitable for various low-voltage applications.

Suitable for

• Indoor electrical junction points
• Surface-mounted cable connections
• Residential and commercial installations

Key specifications

• Product Type: Junction Box
• Mounting Type: Surface-mounted
• Material: Polypropylene (PP)
• Halogen-Free: Yes
• Colour: White
• IP Rating: IP20
• Lid Fastening: Snap-on
• Number of Cable Entries: 8 (knock-out)
• Max Cable Cross-Section: 2.5 mm²
• Rated Voltage: Up to 400V AC
• Rated Current: Up to 16A
• Operating Temperature: -5°C to +60°C
• Glow-Wire Test: 650°C
• Internal Terminals: None (empty box)
• Application: Indoor electrical installations
• Compliance: CE, RoHS

Recommendations

For optimal performance, use with cables up to 2.5 mm² and ensure proper sealing of unused entries. Suitable for dry indoor environments only.
