Donau Elektronik 218-11 Cable flexible 2 x 0,14 mm² negro 5 m

For low-voltage signal and control wiring where flexibility matters, this 2-core stranded wire from Donau Elektronik delivers reliable performance in a compact black jacket. The tinned copper conductors resist corrosion and simplify soldering, while the PVC insulation provides dependable protection in temperatures from -30 to +80 °C. Unlike solid-core alternatives, the 18 x 0.1 mm stranding allows repeated bending without breakage, making it well suited for tight enclosures, prototyping, and equipment interconnect.

Highlights

• 2 cores, each 0.14 mm² cross-section (18 x 0.1 mm tinned copper strands)
• 5 m coil length – ready for multiple small projects or one continuous run
• Black PVC outer jacket, 2.5 mm outer diameter
• Nominal voltage 50 V, test voltage 1200 V
• RoHS compliant

In daily use

The fine stranding keeps the wire pliable, so routing through cable ducts or around corners is straightforward. Tinned copper strands take solder easily and resist oxidation, reducing the risk of dry joints. The black jacket blends neatly into most equipment and is easy to label. With a 5 m coil, you can cut to length for sensor connections, low-voltage lighting, or internal wiring of control panels without waste.

Full specifications

• Product type: stranded wire
• Number of cores: 2
• Conductor cross-section (per core): 0.14 mm²
• Conductor construction: 18 x 0.1 mm
• Conductor material: tinned copper
• Insulation material: PVC
• Outer diameter: 2.5 mm
• Nominal voltage: 50 V
• Test voltage: 1200 V
• Temperature range: -30 to +80 °C
• Length: 5 m
• Colour: black
• RoHS compliant: yes
• Packaging: coil

Final note

A practical choice for hobbyists and professionals who need a flexible, corrosion-resistant hook-up wire in a convenient 5 m length.
