E CORD XP03/01-D1/SY-08 3X1.5 40M 4P R Cable eléctrico industrial 40m negro

The E CORD XP03/01-D1/SY-08 3X1.5 40M 4P R is a high-quality industrial power cable designed for demanding environments. With a 3-core configuration (Live, Neutral, Earth) and a conductor cross-section of 1.5 mm² per conductor, this cable ensures reliable power transmission for industrial machinery, construction sites, and outdoor applications. The cable is 40 meters long, providing ample reach for various setups.

Advantages

This cable offers exceptional durability and flexibility, thanks to its rubber insulation and sheath materials (EPR and PCP/Neoprene). It is highly flexible (Class 5 stranded conductors), making it easy to install in tight spaces. The cable is oil resistant, abrasion resistant, UV resistant, and flame retardant, ensuring long-lasting performance even in harsh conditions. With a rated voltage of 450/750 V and a rated current of 16 A, it is suitable for a wide range of industrial applications.

Suitable for

• Industrial power supply connections
• Construction site equipment
• Outdoor and temporary power installations
• Machinery and heavy equipment

Key specifications

• Cable Type: Industrial Power Cable
• Conductor Configuration: 3-Core (L, N, E)
• Conductor Cross-Section: 1.5 mm²
• Cable Length: 40 m
• Conductor Material: Electrolytic Copper
• Insulation Material: Rubber (EPR)
• Sheath Material: Rubber (PCP/Neoprene)
• Rated Voltage: 450/750 V
• Rated Current: 16 A
• Outer Diameter: Approx. 9.5 mm
• Operating Temperature: -25°C to +60°C
• Cable Color: Black
• Packaging: Coiled

Recommendations

For optimal performance, ensure that the cable is used within its rated voltage and current limits. Avoid sharp bends and excessive tension during installation. Store in a dry, cool place when not in use.
