Telegärtner J01000F1256 Conector macho BNC de crimpado para RG59/RG62/RG223/RG400, 75 ohmios

Coaxial connections in broadcast, video and RF systems often fail because the plug does not match the cable or the crimp is not reliable. The Telegärtner J01000F1256 BNC plug solves this by providing a precise 75 Ohm crimp termination for a wide range of 75 Ohm coaxial cables, including RG 59 B/U, RG 62 A/U, RG 140, RG 210, RG 223, RG 400, URM 90, URM 96, KX 6A, KX 27 and KX 28. Its gold-plated centre contact and nickel-plated brass body ensure stable signal integrity from DC to 1 GHz.

Who is it for

Installers and technicians who build or repair coaxial cable assemblies for CCTV, broadcast, telecommunications and general RF applications. It is also suitable for maintenance teams that need a dependable BNC connector for field terminations.

Main features

• BNC male (plug) connector with crimp termination for cable group G 37.
• 75 Ohm impedance, optimised for video and RF signals up to 1 GHz.
• Gold-plated centre contact and nickel-plated brass body for corrosion resistance and low contact resistance.
• PTFE dielectric ensures stable electrical performance over a wide temperature range from -40 °C to +85 °C.
• Meets IEC 60169-8 dimensional and performance requirements.

Specifications

• Connector type: BNC male (plug)
• Impedance: 75 Ohm
• Frequency range: DC to 1 GHz
• Termination style: Crimp
• Cable group: G 37
• Suitable cables: RG 59 B/U, RG 62 A/U, RG 140, RG 210, RG 223, RG 400, URM 90, URM 96, KX 6A, KX 27, KX 28
• Contact plating: Gold (centre)
• Body plating: Nickel
• Body material: Brass
• Dielectric material: PTFE
• Operating temperature: -40 °C to +85 °C
• Voltage rating: 500 V peak
• Insulation resistance: ≥ 5 GΩ
• Contact resistance: inner ≤ 1.5 mΩ, outer ≤ 1 mΩ
• VSWR: ≤ 1.25 up to 1 GHz
• Durability: 500 mating cycles
• Standard compliance: IEC 60169-8

Tips

Use the correct crimp tool and die set for the cable diameter to achieve a reliable connection. Strip the cable according to the connector's recommended dimensions to avoid short circuits or poor shielding contact.
