Eaton M22-I6 carcasa vacía, 6 posiciones, montaje en suelo, gris RAL 7035 216540

In industrial control panels, the Eaton M22-I6 empty enclosure provides a robust housing for up to six control circuit devices. Its base mounting design suits fixed installations on machinery or walls, and the grey RAL 7035 finish blends with standard equipment. The enclosure is made of thermoplastic, offering a lightweight yet sturdy solution for protecting electrical components.

Key specifications

• Number of installation positions: 6
• Mounting type: Base mounting
• Material: Thermoplastic (Polycarbonate)
• Colour: Grey (RAL 7035)
• Protection class: IP66 / IP67
• Impact resistance: IK03
• Product series: Eaton M22
• Suitable for: Control circuit devices
• Operating temperature range: -25 to 70 °C
• NEMA rating: NEMA 4X, 13
• Halogen-free: Yes
• UV resistance: Yes

Why choose it

The M22-I6 offers a high degree of protection against dust and water, making it suitable for demanding environments. Its halogen-free and UV-resistant construction ensures long-term durability even outdoors. The enclosure is designed to accommodate Eaton M22 control circuit devices, allowing for a customised control station.

Ideal use cases

• Industrial control panels
• Machine building
• Outdoor installations requiring UV resistance
• Applications needing high IP protection

Good to know

The enclosure's compact dimensions (80 x 252 x 56 mm) make it easy to integrate into existing setups. It is part of the Eaton M22 series, known for modularity and reliability.
