EFB Elektronik A-DQ(ZN)B2Y 8E 9/125 µm G.657.A1 PE Cable de fibra óptica para exterior negro

The EFB Elektronik A-DQ(ZN)B2Y 8E 9/125µm G.657.A1 PE is a high-quality outdoor fiber optic cable designed for reliable data transmission in demanding environments. With 8 single-mode fibers and bend-insensitive G.657.A1 technology, this cable ensures low attenuation and robust performance for direct burial or duct installation.

Advantages

This cable offers excellent protection against rodents and UV radiation, making it ideal for long-term outdoor use. Its halogen-free, non-metallic construction provides safety and durability, while the polyethylene outer sheath resists moisture and mechanical stress.

Suitable for

• Outdoor fiber optic networks
• Direct burial applications
• Duct installations
• Telecommunications and data centers

Key specifications

• Fiber type: Single-mode 9/125µm
• Fiber count: 8
• Standard: ITU-T G.657.A1 (bend-insensitive)
• Outer sheath: Polyethylene (PE), black
• Outer diameter: 7.0 mm
• Attenuation: ≤0.35 dB/km @ 1310nm, ≤0.22 dB/km @ 1550nm
• Operating temperature: -20°C to +70°C
• Minimum bending radius: 70 mm (operation)

Recommendations

For optimal performance, use with appropriate connectors and splicing equipment. Ensure proper cable management to maintain bend radius limits.
