EFB Elektronik Caja de empalme 6x LC Dúplex OM4 extraíble, 1U, parcialmente equipada, gris claro

The EFB Elektronik B61901.6OM4 is a high-quality, partially equipped fiber optic splice box designed for professional network infrastructure. It features 6 LC Duplex OM4 adapter ports in a pull-out (extendable) 1U 19-inch rack-mount design, ideal for data centers and server rooms. The steel housing in RAL 7035 light grey ensures durability and a neat appearance.

Advantages

This splice box offers easy access for splicing and patching thanks to its extendable design. The OM4 multimode fiber class supports high-bandwidth applications up to 100 Gbps. With a maximum fiber capacity of 12 fibers and included splice tray, it provides flexibility for future expansions. The rear cable entry points simplify cable management.

Suitable for

• Data centers and server rooms
• Network infrastructure installations
• Fiber optic distribution points
• Structured cabling systems

Key specifications

• Product Type: Fiber Optic Splice Box
• Mounting: 19-inch Rack Mount, 1U
• Design: Pull-out (Extendable)
• Equipping Level: Partially Equipped
• Number of Adapter Ports: 6
• Connector Type: LC Duplex
• Fiber Mode: Multimode OM4
• Maximum Fiber Capacity: 12 Fibers
• Housing Material: Steel
• Color: RAL 7035 (Light Grey)
• Protection Rating: IP20
• Operating Temperature: -10°C to +60°C
• Standards: RoHS, REACH

Recommendations

For optimal performance, use with OM4 patch cables and LC duplex connectors. Ensure proper cable management and grounding according to local regulations.
