ELFON OPTIMA OP-OP1-G Caja de abonado de fibra óptica empotrable grafito para FTTH, SC/LC, 4 empalmes

The ELFON OPTIMA OP-OP1-G is a flush-mounted fiber optic subscriber box engineered for FTTH indoor termination points. Its graphite ABS housing provides a discreet, durable enclosure for single or dual fiber connections, supporting SC simplex and LC duplex adapters with up to four splices.

Advantages

This recessed enclosure blends seamlessly into walls while protecting splices and connectors from dust and accidental contact. The snap-on cover allows quick access for maintenance, and integrated cable management keeps drop cables and patchcords neatly routed. UV-resistant ABS plastic ensures long-term colour stability even near windows, and RoHS compliance confirms environmental responsibility.

Suitable for

• FTTH subscriber termination points in apartments and offices
• Indoor fiber optic installations requiring a clean, flush-mounted finish
• Networks using SC simplex or LC duplex adapters
• Installations with up to four fiber splices
• Environments where space is limited and aesthetics matter

Key specifications

• Enclosure type: Flush-mounted (recessed)
• Material: High-quality ABS plastic, graphite colour
• Adapter compatibility: SC simplex, LC duplex (max 4 adapters)
• Splice capacity: Up to 4 fiber splices
• Ingress protection: IP30
• Operating temperature: -5°C to +50°C
• Storage temperature: -25°C to +60°C
• External dimensions: 120 x 120 x 30 mm
• Internal dimensions: 100 x 100 x 25 mm
• Certifications: RoHS compliant

Recommendations

For a reliable and unobtrusive FTTH termination, the ELFON OPTIMA OP-OP1-G offers the essential features in a compact, easy-to-install package. Its graphite finish suits modern interiors, and the robust ABS construction ensures long service life.
