EPRADO-R19-4U/450-BLUE armario de pared 19 inch 4U, azul (RAL 5012), 450 mm de profundidad, capacidad de carga 60 kg, puerta de vidrio templado

The EPRADO-R19-4U/450-BLUE is a high-quality 19-inch wall mount rack cabinet designed for secure and organized installation of network and IT equipment. With a 4U capacity and a depth of 450 mm, this rack is ideal for small to medium-sized setups where space is at a premium. The cabinet is constructed from cold-rolled steel (SPCC) and finished in a durable blue (RAL 5012) coating, ensuring long-lasting performance and a professional appearance.

Advantages

This wall mount rack offers a robust solution for housing servers, switches, patch panels, and other 19-inch equipment. The tempered glass front door with lock provides visibility while ensuring security. Removable and lockable side panels allow easy access for maintenance and cable management. The top panel is prepared for up to two 120x120 mm fans (not included) to enhance ventilation. With a static load capacity of 60 kg, it can support a variety of equipment. The rack is supplied flat-packed for convenient transport and includes all necessary mounting hardware.

Suitable for

• Network cabinets for small offices, server rooms, or home labs
• Mounting 19-inch equipment such as switches, routers, patch panels, and UPS units
• Applications requiring secure, lockable enclosure with visibility

Key specifications

• Rack Standard: 19-inch
• Rack Units: 4U
• External Dimensions (W x D x H): 600 x 450 x 230 mm
• Colour: Blue (RAL 5012)
• Material: Cold-rolled steel (SPCC)
• Front Door: Tempered glass with lock
• Side Panels: Removable, lockable
• Cable Entry: Top and bottom
• Ventilation: Prepared for 1-2 fans (120x120 mm) in top panel
• Static Load Capacity: 60 kg
• Mounting Type: Wall mount
• Construction: Disassembled (flat-packed)
• IP Protection Rating: IP20
• Mounting Rails: Adjustable depth, 19-inch
• Included Accessories: 2 keys for front door, 4 wall mounting screws, 8 cage nuts with screws
• Compliance: RoHS, CE

Recommendations

For optimal performance, ensure the wall is capable of supporting the total weight of the rack and installed equipment. Use appropriate wall anchors (not included) for secure mounting. Consider adding optional 120x120 mm fans for active cooling if high-power equipment is installed.
