Rack autoportante Rittal VX 8606.000, IP55, cerradura de llave, gris

Industrial control systems and sensitive electronics need a secure, dust- and splash-proof home. The Rittal VX 8606.000 freestanding rack cabinet delivers exactly that: a fully assembled enclosure with IP55 protection, a key-lockable front door, and a sturdy frame that keeps your equipment safe from environmental hazards and unauthorized access.

Who is it for

This cabinet is built for system integrators, plant engineers, and IT technicians who need reliable protection for automation controllers, power distribution components, or network hardware in factories, workshops, or commercial buildings. It suits applications where dust, spraying water, or casual tampering are concerns, but extreme outdoor conditions are not.

Main features

• Complete enclosure system: frame, front door, rear panel, side panels, roof plate, mounting plate, and open base frame included.
• IP55 ingress protection: guards against dust and low-pressure water jets from any direction.
• Key lock with 3-point locking system and comfort handle for profile half-cylinder (cylinder not included).
• Single front door, hinged right, reversible to left if needed.
• Depth-adjustable mounting plate for flexible equipment installation.
• Removable side panels and rear panel for easy access during installation and maintenance.
• Light grey (RAL 7035) powder-coated finish for a clean, professional look.
• Static load capacity up to 1500 kg for heavy equipment.
• Compatible with Rittal VX25 system accessories for expansion and customization.

Specifications

• Brand: Rittal
• Model: VX 8606.000
• MPN: 8606000
• EAN: 4028177813731
• Nominal dimensions (W x H x D): 600 x 2000 x 600 mm
• Material: Sheet steel
• Colour: Light grey (RAL 7035)
• Protection category: IP55
• Door type: Single front door, steel, key lock
• Mounting plate: Included, depth-adjustable
• Roof plate: Included, removable
• Side panels: Two, removable, screw-fastened
• Rear panel: One, removable, screw-fastened
• Base: Open base frame
• Static load capacity: 1500 kg
• Certifications: UL, cUL, TÜV, Germanischer Lloyd, EAC, VDE
• System compatibility: Rittal VX25

Tips

For cable entry, use the divided gland plates in the base to maintain the IP55 seal. If you need to reverse the door hinge, follow the instructions in the manual—no special tools required. To expand the cabinet into a suite, join multiple VX25 enclosures side-by-side using the optional baying kit.
