Gira TX_44 toma SCHUKO con tapa abatible y campo de rotulación, blanco puro 441065

In damp rooms or sheltered outdoor areas, a standard socket outlet is a weak point: moisture can reach the contacts and cause short circuits or corrosion. The Gira TX_44 SCHUKO socket outlet with hinged cover solves this by sealing the socket behind a self-closing lid that keeps splashing water and dust away when the outlet is not in use.

Who is it for

Electricians and homeowners who need a reliable, flush-mounted SCHUKO socket in bathrooms, utility rooms, covered terraces, or garages. It fits standard flush-mounted boxes and pairs with Gira TX_44 frames and sealing sets for a clean, uniform look.

Main features

• SCHUKO socket outlet (Type F) with hinged cover
• Integrated inscription field for labeling circuits or locations
• Pure white thermoplastic housing, UV- and impact-resistant
• Nominal voltage 250 V AC, nominal current 16 A
• Protection rating IP44 with cover closed
• Flush-mounted installation, screw terminals for conductors up to 2.5 mm² rigid
• Halogen-free material

Specifications

• Socket type: SCHUKO (Type F)
• Number of sockets: 1
• Mounting type: Flush-mounted
• Connection type: Screw terminals
• Nominal voltage: 250 V AC
• Nominal current: 16 A
• Protection rating: IP44 (with hinged cover closed)
• Impact resistance: IK07
• Material: Thermoplastic, UV-resistant, halogen-free
• Colour: Pure white
• Operating temperature: -25 °C to +45 °C
• Compatibility: Gira TX_44 frames and sealing sets

Tips

For outdoor use under direct rain, combine this outlet with a Gira TX_44 sealing set and an appropriate weatherproof enclosure. The inscription field accepts standard labels for clear circuit identification.
