Grabador IP TC-R31640 40 canales H.265 8MP 2 SATA

The TC-R31640 is a high-performance 40-channel IP network video recorder designed for professional surveillance systems. Supporting H.265/H.264 compression, it delivers up to 8MP resolution recording with efficient bandwidth usage. With 2 SATA bays supporting up to 10TB each, it offers ample storage for long-term recording. Advanced analytics including perimeter protection, face detection, and object counting make it ideal for security applications.

Advantages

Supports 40 IP channels with 256 Mbps incoming bandwidth, enabling high-resolution recording from multiple cameras. H.265 compression reduces storage requirements without compromising image quality. Smart analytics provide proactive security alerts. Dual SATA bays allow up to 20TB total storage. HDMI 4K output ensures clear local monitoring.

Suitable for

• Medium to large retail stores
• Office buildings and corporate campuses
• Warehouses and logistics centers
• Educational institutions
• Government facilities

Key specifications

• Video Input: 40 IP channels
• Compression: H.265 / H.264
• Max Recording Resolution: 8MP (3840x2160)
• Video Output: 1x HDMI (up to 4K), 1x VGA
• Incoming Bandwidth: 256 Mbps
• Outgoing Bandwidth: 128 Mbps
• Decoding: 2-ch@8MP, 4-ch@4MP, 8-ch@1080P
• Audio: 1-ch RCA in, 1-ch RCA out
• Alarm: 16-ch in, 4-ch out
• HDD Bays: 2 SATA, up to 10TB each
• Network: 1x Gigabit Ethernet
• USB: 1x USB 2.0 (front), 1x USB 3.0 (rear)
• Power: DC 12V, <10W (without HDD)
• Operating Temperature: -10°C to 55°C

Recommendations

For optimal performance, use with compatible IP cameras supporting H.265 and 8MP resolution. Install enterprise-grade hard drives rated for surveillance use. Ensure network infrastructure supports 256 Mbps bandwidth.
