Hager ZM35PE barra de cobre 180x9mm

Equipotential bonding bar made of solid electrolytic copper for reliable grounding and neutral distribution in electrical installations. The rigid, uninsulated bar provides a cross-sectional area of 81 mm² and a current capacity of 160 A to 200 A, ensuring low-resistance connections for safety and performance.

Advantages

High-conductivity E-Cu material guarantees excellent electrical performance. The solid design withstands mechanical stress and offers long-term durability. Its compact dimensions allow easy integration into distribution boards and control panels.

Suitable for

• Equipotential bonding in main and sub-distribution boards
• Grounding and neutral busbar applications
• General electrical installations requiring reliable current distribution

Key specifications

• Length: 180 mm
• Cross-section: 9 x 9 mm (81 mm²)
• Material: Electrolytic copper (E-Cu)
• Current rating: 160 A to 200 A
• Uninsulated, 1-pole

Recommendations

For secure mounting, use appropriate busbar holders or clamps. Ensure proper sizing of conductors and torque settings during installation.
