Terminal de anillo de crimpaje, aluminio, 16mm² para cable, 10 uds.

This set of 10 aluminium crimp ring terminals is designed for secure and reliable connections on 16mm² cables. Each terminal features a robust, non-insulated construction with a 180° horizontal ring shape, ensuring a stable and durable electrical joint. The aluminium material is chemically treated to minimise contact resistance and corrosion, while the solid body helps prevent moisture ingress.

Key features

• Cable cross-section: 16.0mm²
• Material: aluminium ≥99.5%
• Ring inner diameter: 8.5mm; outer diameter: 16mm
• Terminal length: 70mm; depth: 32mm
• Terminal inner diameter: 6.4mm; outer diameter: 11mm
• Connection angle: 180° (horizontal)
• Set includes: 10 pieces
