HOLZMANN MASCHINEN MF7IN1 Máquina multifunción 7 en 1

The HOLZMANN MASCHINEN MF7IN1 is a versatile 7-in-1 multifunctional woodworking machine designed for professional workshops. Combining planer, thicknesser, circular saw, spindle moulder, and mortiser functions, it offers exceptional flexibility and space-saving efficiency. Powered by a robust 3.1 kW motor (S6) with 400V three-phase supply, this machine delivers reliable performance for demanding tasks.

Advantages

Space-saving design integrates multiple woodworking operations into one compact unit. High motor power ensures efficient material removal. Precision engineering provides accurate cuts and smooth finishes. Durable construction guarantees long service life.

Suitable for

• Professional carpenters and joiners
• Furniture makers and cabinet shops
• Workshops with limited floor space
• Educational institutions and training centers

Key specifications

• Functions: Planer, Thicknesser, Circular Saw, Spindle Moulder, Mortiser
• Motor Power (S6): 3.1 kW
• Motor Power (S1): 2.2 kW
• Voltage: 400V / 3 Phase
• Max Planing Width: 250 mm
• Max Planing Depth: 3 mm
• Max Thicknessing Height: 195 mm
• Thicknesser Feed Speed: 8 m/min
• Saw Blade Diameter: 250 mm
• Max Saw Cutting Height (90°): 75 mm
• Spindle Moulder Shaft Diameter: 30 mm
• Spindle Moulder Speeds: 3500 / 5500 / 7000 rpm
• Number of Planer Knives: 3
• Dust Extraction Port Diameter: 100 mm
• Main Table Dimensions: 960 x 400 mm
• Mortising Chuck Capacity: 16 mm
• Table Height: 850 mm

Recommendations

For optimal performance, use sharp blades and proper dust extraction. Ensure adequate ventilation and follow safety guidelines. Regular maintenance will extend machine life.
