KONTAK-SIMON Simon 54 módulo de enchufe negro mate, 1x tipo F, protección infantil, bornes de tornillo 16A 250V

Upgrading your electrical installation with a single socket that blends seamlessly into a premium switch range is rarely straightforward. The KONTAK-SIMON Simon 54 module solves exactly that: a flush-mounting black matt socket outlet that integrates into a 75x75mm mechanism, delivering reliable power where you need it while matching modern interior styling.

Who is it for

This module suits electricians, builders, and renovation enthusiasts installing a Simon 54 system. Whether you are completing a new wiring project or replacing worn-out sockets, this component provides a sturdy, child-safe power point for residential and commercial interiors. It is an ideal choice for living areas, bedrooms, home offices, or any space where you want consistent 16A performance and a low-key dark finish.

Main features

• 1x Type F (Schuko) socket with earthing pin for universal two-pole plus earth compatibility
• Integrated child-protection shutters to prevent accidental insertion in daily use
• Secure screw terminals ensure reliable wiring and long-term contact stability
• Rated for 16A at 250V AC, covering standard household and light commercial loads
• Flush-mount mechanism with 75x75mm footprint and 28mm installation depth
• Black matt plastic (PC/ABS) surface that resists fingerprints and complements dark décor

Specifications

• Brand: KONTAK-SIMON
• Model: DGZ1Z.01/49
• MPN: DGZ1Z.01/49
• EAN: 5902787870898
• Product colour: Black Matt
• Socket type: Type F (grounded, with shutters)
• Rated current: 16 A
• Rated voltage: 250 V AC
• Frequency: 50/60 Hz
• Connection type: Screw terminals
• Mounting: Flush mount
• Installation depth: 28 mm
• Module dimensions: 75 x 75 mm
• IP rating: IP20
• Certification: CE

Tips

Turn off power at the circuit breaker before installation. This module fits a standard 75x75mm flush-mount box and works with Simon 54 frames and plates. Pair it with a matching black matt cover plate for a seamless finish. Check local wiring regulations and terminal torques to ensure a safe connection.
