LANVIEW J9143B Switch gestionado L3 HPE ProCurve de 24 puertos Gigabit con 4 uplinks SFP+, capacidad de conmutación de 128 Gbps

With a 128 Gbps switching fabric and 95.2 Mpps forwarding rate, the LANVIEW J9143B HPE ProCurve delivers wire-speed performance for demanding enterprise edge and aggregation deployments. This 1U rack-mountable Layer 3 managed switch combines 24 Gigabit Ethernet ports (20 fixed 10/100/1000 plus 4 dual-personality SFP/1000BASE-T) with 4 dedicated 10GbE SFP+ uplinks, giving you flexible high-bandwidth connectivity for servers, storage, and uplinks to the core.

Overview

The J9143B is a full-featured Layer 2/3 switch with static IP routing and RIP, IEEE 802.1Q VLANs, link aggregation (LACP), and robust security including 802.1X and password protection. It supports jumbo frames up to 9220 bytes for efficient storage and virtualization traffic. Management options include CLI, web GUI, SNMP, and RMON, with a system event log for troubleshooting. The switch is powered by an internal 50 W power supply and offers a high MTBF of 200,000 hours for reliable operation.

What stands out

• 24 Gigabit ports with 4 dual-personality SFP/copper ports for flexible media choices
• 4 SFP+ 10GbE uplinks for high-speed aggregation
• Layer 3 static routing and RIP for inter-VLAN communication
• Comprehensive management: CLI, web, SNMP, RMON
• Jumbo frame support up to 9220 bytes
• 1U rack-mountable form factor

Technical details

• Switching capacity: 128 Gbps
• Forwarding rate: 95.2 Mpps
• MAC address table: 16,000 entries
• RAM: 512 MB SDRAM; Flash: 1 GB
• Power consumption: 50 W (operational)
• MTBF: 200,000 hours
• Standards: IEEE 802.3, 802.3u, 802.3ab, 802.1D, 802.1Q, 802.1p, 802.1w, 802.1s, 802.1x, 802.3ad
• Dimensions (WxDxH): 44.25 cm x 24.64 cm x 4.39 cm; weight: 3.4 kg

Our verdict

The LANVIEW J9143B HPE ProCurve is a solid choice for organizations needing a reliable, high-performance L3 managed switch with 10GbE uplinks. Its combination of port density, Layer 3 capabilities, and management features makes it well-suited for branch offices, campus access, and small to medium core deployments.
