LANVIEW Quick Assembly Flat Pack 19 9U armario de red de montaje en pared, negro, 600x464x450mm

The LANVIEW Quick Assembly Flat Pack 19 is a wall-mount 19-inch network cabinet designed for efficient space utilisation and rapid deployment. It arrives as a flat pack, cutting down on transport costs and making it easier to move into tight spaces, while the straightforward assembly means you can have it installed and populated in no time. With a 9U height, it suits SMB networks, server rooms, or any location where floor space is at a premium.

Highlights

• 19-inch rack compatibility
• 9U height – compact yet spacious
• Quick assembly flat pack design
• Tempered glass front door – see the status of your equipment
• Lockable front door and side panels for security
• Removable side panels simplify cable installation
• Cable entry points top and bottom with brush strips
• Static load capacity of 60 kg

In daily use

Assembling this cabinet is straightforward; all components and a full set of cage nuts and screws are included. The two side panels can be completely removed, giving unimpeded access to the interior while you mount switches, patch panels, or other devices. The lockable front door allows monitoring of LEDs without opening the cabinet, and the lockable side panels prevent unauthorised access to cabling. The top and bottom openings with brush strips keep cables tidy and maintain a clean finish.

Full specifications

• Rack units (U): 9U
• Rack width: 19 inch
• External dimensions (W x H x D): 600 x 464 x 450 mm
• Internal usable depth: approx. 370 mm
• Material: SPCC cold rolled steel
• Finish: powder coated
• Colour: black (RAL9004)
• Front door: tempered glass with perforated steel frame (lockable)
• Side panels: removable and lockable
• Rear panel: solid
• Mounting: wall mount
• Assembly: flat pack, quick assembly
• Static load capacity: 60 kg
• Ventilation: passive (perforated door, ready for fan unit)
• Compliance: ANSI/EIA RS-310-D, IEC297-2, DIN41494 PART1, DIN41494 PART7
• Accessories: 2 keys, 20 cage nuts and screws

Final note

This LANVIEW cabinet offers a balance of security, convenience, and build quality. The tool-free fastening of the frame in the flat pack design means you can have it operational in minutes, while the rugged steel construction and powder-coated finish ensure years of trouble-free service. For a space-saving, secure housing for your network gear, this is a reliable choice.
