Foco LED OEM VISIONAL VS-FL-30-PIR-IP65/W — 30W, 3600 lm, sensor PIR, IP65

Outdoor LED floodlight VISIONAL VS-FL-30-PIR-IP65/W is a 30 W fixture that provides 3600 lm of neutral-white light (6000 K). The luminaire operates from AC170–265 V and has a compact slim design with dimensions Ø300×55 mm. An integrated PIR motion sensor enables automatic activation, while the IP65 rating makes the floodlight suitable for exterior installation where protection against dust and water is required.

Advantages

The VISIONAL VS-FL-30-PIR-IP65/W offers energy-efficient lighting at 30 W with high luminous flux, an integrated PIR sensor for motion-activated operation, and robust IP65 ingress protection for outdoor environments. Its slim round form factor and wide operating voltage range simplify installation on facades, under eaves or on poles.

Suitable for

• Building facades and exterior walls
• Driveways and entrances
• Residential yards and gardens
• Security and perimeter lighting with motion activation

Key specifications

• Power consumption: 30 W
• Luminous flux: 3600 lm
• Light colour temperature: 6000 K (neutral-cool white)
• Voltage: AC 170–265 V
• Ingress protection: IP65
• Dimensions: Ø300 × 55 mm
• Integrated sensor: PIR motion sensor
• Model / MPN: VS-FL-30-PIR-IP65/W
• EAN: 4752233015110

How to use

Mount the floodlight on a stable surface using appropriate fasteners for the installation site and connect to the AC170–265 V supply following local electrical regulations. Position the PIR sensor so its detection zone covers the intended area and adjust the mounting angle to avoid false triggers. After wiring and secure mounting, test the motion activation and make any required orientation or sensitivity adjustments according to the sensor instructions.

Recommendations

For reliable operation, install the luminaire at a height and angle that ensures the PIR sensor has a clear view of the monitored area and avoid pointing the sensor toward heat sources or reflective surfaces. Ensure electrical connections are made by a qualified person and that the fixture is sealed against direct water jets beyond its IP65 rating.
