Foco LED OEM VS-FL-30-IP65/W 30W, 3600 lm, IP65

OEM VS-FL-30-IP65/W is a 30W LED floodlight that delivers 3600 lumens of cool white light (6000 K) and is rated IP65 for protection against dust and water. With an input voltage range of AC 170–265 V and compact dimensions of Ø300 x 55 mm, the fixture is suitable for both outdoor and indoor locations where robust, energy-efficient general illumination is required.

Advantages

The floodlight provides high luminous efficacy at 30 W, low operating costs compared with conventional lighting, and protection against dust and splashing water thanks to its IP65 rating. Its wide input voltage range supports stable operation on standard AC supplies, and the compact round design simplifies mounting and integration into façades, signage, or work-area installations.

Suitable for

• Facade and architectural accent lighting
• Signage and billboards
• Outdoor work areas and loading zones
• Security and perimeter lighting
• Indoor spaces requiring moisture- or dust-resistant fixtures

Key specifications

• Power consumption: 30 W
• Luminous flux: 3600 lm
• Light colour temperature: 6000 K (cool white)
• Ingress protection: IP65
• Input voltage: AC 170–265 V
• Dimensions: Ø300 x 55 mm
• Model / MPN: VS-FL-30-IP65/W

How to use

Mount the LED floodlight on a stable surface using appropriate fasteners for the installation substrate. Connect the fixture to a compatible AC supply within the specified 170–265 V range, ensuring power is turned off during wiring. Observe correct polarity and grounding where applicable. After installation, switch on the power to verify operation and adjust the aim of the floodlight as required for the desired coverage.

Recommendations

Install the luminaire in locations protected from severe mechanical impact. For long-term performance, avoid covering the fixture and allow adequate ventilation around the housing. Regularly check mounting hardware and cable connections; clean external surfaces with a soft, dry cloth and avoid abrasive cleaners or high-pressure water jets despite the IP65 rating.
