LogiLink Professional Cat.6A STP keystone jack RJ45, IP68 industrial para exteriores, sin herramientas, zamak, negro

When standard keystone jacks fail under harsh conditions, the LogiLink NP0085 stands out with its IP68-rated zinc die-cast housing, built to survive dust, water, and industrial environments where ordinary modules simply cannot. This Cat.6A STP keystone jack delivers 10 Gigabit Ethernet performance with tool-free termination, making it the go-to choice for outdoor and factory installations that demand reliability without compromise.

Highlights

• IP68 dustproof and waterproof protection for outdoor and industrial use
• Supports 10 Gigabit Ethernet over Cat.6A shielded twisted pair
• Tool-free IDC termination saves installation time and effort
• Rugged zinc die-cast nickel-plated housing withstands tough conditions
• Gold-plated phosphor bronze contacts ensure long-term signal integrity
• PoE, PoE+, and PoE++ ready for powering devices over Ethernet

In daily use

Installation is quick and secure: simply press the wires into the color-coded IDC slots without any special tools. The module snaps into any standard keystone wall plate or patch panel, and the shielded design minimizes electromagnetic interference. Whether you're wiring an outdoor camera, a factory sensor, or a high-speed access point, this jack maintains a stable 10G link even in demanding conditions.

Full specifications

• Product type: Keystone module
• Network category: Cat.6A (Class EA)
• Connector type: RJ45 jack (8P8C)
• Shielding: STP (shielded twisted pair)
• IP rating: IP68 (dustproof and waterproof)
• Application environment: Industrial, outdoor
• Connection method: Tool-free IDC
• Cable compatibility: Solid and stranded wires, AWG 22-26
• Contact material: Phosphor bronze, gold-plated (50µ")
• Housing material: Zinc die-cast, nickel-plated
• Transmission speed: Up to 10 Gigabit Ethernet
• PoE support: PoE, PoE+, PoE++ (IEEE 802.3af/at/bt)
• Standards compliance: ISO/IEC 11801, EN 50173, TIA/EIA-568-C.2
• Operating temperature: -20°C to +70°C
• Mounting type: Standard keystone port (19.2 x 14.9 mm)
• Colour: Black

Final note

For installers who need a keystone jack that won't quit when the weather turns or the dust flies, the LogiLink NP0085 is the professional's choice — built to last, easy to terminate, and ready for 10G.
