MEAN WELL MDR-10-12 Fuente de alimentación para carril DIN 12V DC 0,84A 10W

Compact DIN rail power supply delivering stable 12 V DC output for industrial control systems. With a slim 10 W capacity and universal AC input, it fits seamlessly into crowded control cabinets.

Advantages

Built for reliability, the MDR-10-12 offers short circuit, overload, and over voltage protection, ensuring continuous operation. Its free air convection cooling eliminates fan noise and maintenance, while the wide operating temperature range from -20 to +70 °C suits harsh environments. The plastic housing is lightweight yet durable, and the DIN rail mount allows quick installation on TS-35/7.5 or TS-35/15 rails.

Suitable for

• Industrial automation and control panels
• Building management systems
• Sensor and actuator power supply
• Small-scale machinery and equipment

Key specifications

• Output: 12 V DC, 0.84 A, 10.08 W
• Input: 85-264 V AC or 120-370 V DC
• Efficiency: 80%
• Protections: Short circuit, overload, over voltage
• Operating temperature: -20 to +70 °C
• Certifications: UL508, TUV EN60950-1, CB, CE
• MTBF: >500,000 hours

Recommendations

For engineers seeking a dependable power source in space-constrained installations, the MDR-10-12 delivers consistent performance with essential protections and global certifications.
