MEAN WELL RSP-750-24 Fuente de alimentación cerrada 750W 24V 31,3A con PFC y perfil bajo 1U

The MEAN WELL RSP-750-24 is a high-density enclosed AC/DC power supply delivering 750W of continuous output at 24V DC. Its active power factor correction and 91.5% efficiency make it a reliable backbone for industrial automation, LED lighting, and communication systems that demand stable power in a compact 1U form factor.

Advantages

Built for demanding environments, this unit features a built-in DC fan with speed control for optimal thermal management, plus comprehensive protections against short circuit, overload, over voltage, and over temperature. Remote ON/OFF, remote sense, and a DC OK signal simplify system integration, while current sharing supports up to 3000W with four parallel units.

Suitable for

• Industrial control systems and factory automation
• LED signage and architectural lighting
• Telecom and networking equipment
• Test and measurement instruments
• Redundant power configurations

Key specifications

• Output: 24V DC, 31.3A, 750W
• Input: 90–264V AC, 47–63Hz
• Efficiency: up to 91.5%
• Active PFC (>0.95 at full load)
• Form factor: 1U low profile enclosed
• Cooling: built-in DC fan with speed control
• Protections: short circuit, overload, over voltage, over temperature
• Operating temperature: -20°C to +70°C
• Ripple & noise: 150mVp-p
• Safety: UL60950-1, TUV EN60950-1
• EMC: EN55022 Class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11
• MTBF: >200K hrs (MIL-HDBK-217F)

Recommendations

For engineers and system integrators seeking a dependable power solution with high power density and advanced control features, the RSP-750-24 offers an excellent balance of performance, reliability, and value. Its 1U profile saves rack space, and the built-in fan ensures quiet, efficient cooling under load.
