MITON MT-P1260 caja de derivación de superficie 120x60x50mm IP65 gris claro

The MITON MT-P1260 is a robust surface-mounted junction box designed for indoor and outdoor electrical installations. Manufactured from high-quality ABS plastic with a light grey (RAL 7035) finish, this enclosure offers excellent durability and protection against dust and water jets with an IP65 rating. Its compact dimensions (120 x 60 x 50 mm) make it ideal for a wide range of applications, including networking, security, and electrical connections.

Advantages

This junction box provides reliable protection for your connections in harsh environments. The IP65 rating ensures it is dust-tight and protected against low-pressure water jets, making it suitable for outdoor use. The IK07 impact resistance adds mechanical protection, while the UV-resistant and halogen-free materials ensure long-term performance and safety. The smooth walls allow for custom drilling of cable glands, offering flexibility in installation.

Suitable for

• Electrical junction and connection boxes for indoor and outdoor use
• Network and communication installations requiring IP65 protection
• Security system enclosures for cameras and sensors
• Industrial control and automation applications
• DIY and professional electrical projects

Key specifications

• Product Type: Surface-mounted junction box
• External Dimensions (L x W x H): 120 x 60 x 50 mm
• Internal Dimensions (L x W x H): 115 x 55 x 45 mm
• Material: ABS plastic, light grey (RAL 7035)
• IP Rating: IP65
• Impact Resistance: IK07
• Lid Fastening: 4 plastic screws
• Gland Entries: Smooth walls for custom drilling
• Operating Temperature: -25°C to +70°C
• Flammability Rating: UL94-V2
• UV Resistant: Yes
• Halogen-Free: Yes
• Wall Thickness: 2.5 mm
• Certifications: CE compliant

Recommendations

For optimal performance, use appropriate cable glands and ensure proper sealing of all entries. This enclosure is designed for surface mounting; ensure the mounting surface is clean and dry before installation. Suitable for use with a wide range of cables and connectors.
