Phoenix Contact ZB 6 tiras de marcado en zigzag, numeración 31-40, 10 marcadores, blanco, paso 6,2 mm

The Phoenix Contact ZB 6 Zack Marker Strip is a high-quality terminal block marking solution designed for clear and durable identification of electrical connections. This strip features consecutive numbering from 31 to 40, providing 10 individual markers per strip. Made from polyamide (PA) with a white color, it offers excellent resistance to wiping, solvents, and UV radiation, ensuring long-lasting legibility in industrial environments.

Advantages

• Clear consecutive numbering for easy identification
• Snap-on mounting for quick installation
• Halogen-free and RoHS compliant for environmental safety
• Wide operating temperature range from -40 °C to 100 °C
• UL 94 V2 flammability rating for enhanced safety

Suitable for

• Terminal block marking in control cabinets and distribution panels
• Identification of electrical circuits and components
• Industrial automation and building infrastructure

Key specifications

• Marker Type: Zack Marker Strip
• Series: ZB 6
• Printing: Consecutive numbers 31-40
• Number of markers per strip: 10
• Color: White
• Material: Polyamide (PA)
• Flammability rating: UL 94 V2
• Mounting: Snap-on
• Compatible terminal block pitch: 6.2 mm
• Marker width: 6.15 mm
• Marker height: 10.5 mm
• Operating temperature: -40 °C to 100 °C
• Resistance to wiping: DIN EN 61010-1 (VDE 0411-1)
• Halogen-free: Yes
• RoHS compliant: Yes
• Product family: CLIPLINE complete

Recommendations

For optimal marking results, use with Phoenix Contact terminal blocks of 6.2 mm pitch. Ensure clean and dry surfaces before snap-on installation.
