Placa de montaje HAGER UD42A1 600x500mm para bloques de bornes, acero galvanizado

Electricians and panel builders working with HAGER Linergy FM distribution boards can use the UD42A1 mounting plate to install terminal blocks and other DIN-rail components. This galvanized steel plate fits enclosures with a nominal size of 600x500 mm and provides a useful area of 550x450 mm.

Key specifications

• Product type: Mounting plate
• Brand series: Linergy FM
• Material: Galvanized steel
• Plate height (useful): 550 mm
• Plate width (useful): 450 mm
• Plate thickness: 2 mm
• Compatible enclosure nominal height: 600 mm
• Compatible enclosure nominal width: 500 mm
• Mounting location: Front, back, side
• Fixing mode: Screw-fixed (M8 screw type)
• Colour: Metallic grey
• Net weight: 2.5 kg

Why choose it

The plate's galvanized surface resists corrosion, making it suitable for long-term use in electrical installations. Its 2 mm thickness provides a sturdy base for mounting heavy terminal blocks or other components.

Ideal use cases

• Mounting terminal blocks in distribution boards
• Installing DIN-rail components in industrial enclosures
• Organizing wiring in control panels

Good to know

The plate is fixed with M8 screws (not included). It is sold individually.
