Cable HDMI FiberX FX-I350-015 15m Type-A conector macho 2.0 18Gbit/s negro plata

The FiberX FX-I350-015 is a 15 m hybrid active optical HDMI 2.0 cable that transmits uncompressed audio and video up to 100 m using a combination of fiber and copper conductors. Designed for professional AV installations, the cable supports full 18 Gbps bandwidth, CEC, transparent EDID and HDCP, zero frame delay and digital audio while remaining flexible with a small bend radius and pre-assembled HDMI Type A male connectors.

Advantages

The hybrid construction combines fiber for long-distance AV transmission and copper for power and control lines, enabling lossless 4K@60Hz (18 Gbps) over long runs without external power. The cable offers gold-plated precision contacts, full-metal HDMI housings, EMI resistance, low attenuation and an integrated chipset with reclocking and full pass-through of EDID, CEC and HDCP to avoid compatibility issues.

Suitable for (tasks / use cases)

• Connecting sources to displays in meeting rooms, auditoriums and control rooms
• Long-distance HDMI runs for digital signage and video walls
• Connecting media players, set-top boxes, consoles or PCs to projectors and large TVs
• Professional AV installations requiring reliable 4K@60Hz transmission

Key specifications

• Model: FiberX FX-I350-015
• Cable length: 15 m (part of series up to 100 m)
• HDMI version: 2.0 (18 Gbit/s)
• Resolution support: up to 4K UltraHD (2160p) @ 60 Hz
• Connector type: HDMI Type A male — HDMI Type A male, full-metal housing
• Cable type: hybrid active optical cable (fiber + copper), Ø 4.5 mm
• Audio: DTS-HD Master Audio, Dolby Digital Plus, Dolby TrueHD
• Features: gold-plated contacts, EMI resistant, low attenuation, no external power required, reclocking chipset
• Colour: Black, Silver

How to use

Identify the clearly marked TX (source) and RX (display) ends and plug the HDMI Type A male connectors into the source device and display respectively. The cable is plug-and-play; typical setups do not require additional drivers or power. Avoid forcing the connector into non‑HDMI ports or using adapters that may not be supported. Observe the minimum bend radius (approximately 60 mm) when routing the cable to prevent damage.

Recommendations

For reliable operation in professional installations, test source‑to‑display compatibility before final installation, route the cable to avoid sharp bends and secure both ends. Do not connect the cable to non‑HDMI or incorrectly labeled ports; compatibility with HDMI adapters is not guaranteed.
