Rittal Mini Comfort tirador AX 1485.600 para armarios compactos y de TI, zamak, RAL 7035

In control cabinet construction, quick yet secure access is essential. The Rittal Mini Comfort Handle AX 1485.600 provides a robust quarter-turn locking solution for AX compact, stainless steel, and IT enclosures. Its swivelling design and tool-free installation make it a practical choice for panel builders and system integrators who need reliable door locking without complex assembly.

Key specifications

• Product type: Mini Comfort Handle
• Compatibility: Rittal AX Compact Enclosures, AX Stainless Steel Enclosures, AX IT Enclosures
• Material: Die-cast zinc
• Colour: RAL 7035 (light grey)
• Surface finish: Powder-coated
• Locking mechanism: Quarter-turn, suitable for various lock inserts (27 mm profile half-cylinder, 40 mm profile half-cylinder, double-bit, square, triangular)
• Protection category with appropriate insert: IP 65
• Mounting: Tool-free installation
• Handle design: Swivelling
• Supply includes: 1 handle, 1 cam, 1 screw, 1 washer
• Overall dimensions (W x H x D): 40 mm x 120 mm x 30 mm
• Net weight: 0.1 kg

Why choose it

This handle combines a compact footprint with high functionality. The die-cast zinc construction and powder coating ensure durability in industrial environments, while the quarter-turn mechanism allows for quick locking and unlocking. Its compatibility with standard lock inserts means you can integrate it into existing keying systems, enhancing security without extra hardware.

Ideal use cases

• Locking doors on Rittal AX compact enclosures in machine building and automation.
• Securing AX stainless steel enclosures in food processing or pharmaceutical applications.
• Providing access control for AX IT enclosures in data centres or network cabinets.
• Retrofitting existing enclosures with a reliable, tool-free handle solution.

Good to know

The handle is supplied with a cam, screw, and washer, so you have everything needed for immediate installation. The IP 65 protection rating is achieved when used with an appropriate lock insert, ensuring resistance to dust and water jets. The swivelling handle design saves space and prevents accidental snagging, making it suitable for tight installations.
