Samsung WMN-55VD 139,7 cm (55") negro

The Samsung WMN-55VD is a white display mount designed for 55" (139.7 cm) Samsung UD/UE Series video wall panels. Sized specifically for these screens, the mount simplifies installation by allowing integrators to fix the mount first and then insert the display, ensuring dimensional consistency and reducing setup time. The mount supports both landscape and portrait orientations and provides a slim profile that helps hide cables and keeps the display close to the wall.

Advantages

The WMN-55VD mount offers three-axis fine adjustment (x-axis vertical with rotational screws, y-axis horizontal, and z-axis push/pull pop-up) to eliminate bezel gaps and align adjacent displays precisely. Its industry-leading slim depth of 39 mm reduces visual clutter by allowing cables to be routed behind the mount and keeps displays closely aligned to the wall for a clean appearance. As a purpose-sized accessory for Samsung UD/UE Series video walls, it reduces installation complexity and the need for additional mounts when switching between landscape and portrait modes.

Suitable for

Key specifications

How to use

Install the WMN-55VD by fixing the mount to a structurally sound wall according to local building codes and the mount installation instructions. Attach the mount first, use the mount's adjustment mechanisms to set approximate alignment, then lift the 55" display into the mount. Use the x-, y- and z-axis fine-tuning features to align bezels with adjacent panels and adjust orientation for landscape or portrait placement. Ensure the display's weight does not exceed the 29 kg capacity and that VESA hole pattern matches one of the supported sizes.

Recommendations

Use qualified installers for video wall setups, check wall structure and fasteners for the combined load, and route power and signal cables before final alignment so cables are hidden behind the slim mount. Verify VESA compatibility (400 x 400 mm to 600 x 400 mm) and confirm the display weight is within the 29 kg limit before mounting.
