VOLTCRAFT VC-9486110 pinza amperimétrica digital con calibración ISO, CAT II 600 V / CAT III 300 V, 2000 cuentas, corriente AC hasta 200 A, tensión AC/DC hasta 600 V, resistencia, capacidad, frecuencia, NCV, linterna

For electricians and service technicians who need dependable measurements without second-guessing their tools, the VOLTCRAFT VC-9486110 stands out with its ISO calibration certificate, confirming accuracy right out of the box. This digital clamp meter handles AC current up to 200 A without breaking the circuit, while also covering AC/DC voltage to 600 V, resistance, capacitance, and frequency. Its CAT III 300 V / CAT II 600 V safety rating makes it suitable for a wide range of electrical tasks, from panel work to appliance repair.

Highlights

• ISO calibrated for documented measurement reliability
• 2000-count digital display with clear readings
• AC current measurement up to 200 A via 25 mm jaw opening
• AC/DC voltage up to 600 V, resistance to 20 MΩ, capacitance to 200 µF, frequency to 20 kHz
• Non-contact voltage (NCV) detection and built-in flashlight for safe work in dark areas
• Data hold, auto-ranging, diode test, and continuity with acoustic signal
• Powered by 2x AAA batteries (included)

In daily use

The VC-9486110 is built for convenience. The clamp jaw opens to 25 mm, enough for most conductors in residential and commercial panels. Auto-ranging eliminates manual range selection, speeding up measurements. The NCV function lets you quickly check for live wires without contact, and the flashlight helps when working in poorly lit cabinets. Data hold freezes the reading on screen, so you can record values even in awkward positions. The continuity buzzer provides clear audio feedback, and the low battery indicator prevents unexpected shutdowns.

Full specifications

• Display: 2000 counts, digital
• AC current: 0.1 A – 200 A, basic accuracy ±(2.5% + 5 digits)
• DC voltage: 0.1 V – 600 V
• AC voltage: 0.1 V – 600 V
• Resistance: 0.1 Ω – 20 MΩ
• Capacitance: 1 nF – 200 µF
• Frequency: 10 Hz – 20 kHz
• Jaw opening: 25 mm
• Safety rating: CAT III 300 V, CAT II 600 V
• Functions: AC current, AC/DC voltage, resistance, capacitance, frequency, diode test, continuity test
• Special features: data hold, auto-range, NCV, flashlight, low battery indicator
• Power supply: 2x AAA batteries
• Calibration: ISO calibrated

Final note

Whether you're troubleshooting a motor, verifying a circuit, or performing routine maintenance, the VOLTCRAFT VC-9486110 delivers the accuracy and safety you need, backed by ISO calibration for professional confidence.
