Anclaje para clavar FISCHER N 6x60/30 S — 100 piezas, fijación de acero para mampostería

Nail anchor FISCHER N 6x60/30 S — 100 pcs is a steel mechanical fastener intended for anchoring into masonry and concrete. The designation 6x60/30 reflects the anchor's diameter and length dimensions; the S variant specifies the steel material. Supplied in a bulk pack of 100, this fixing is designed for routine construction and installation tasks where a compact, hammer-driven anchor is required. Installation into solid substrates provides a direct, friction-based hold suitable for light to medium loads such as rails, brackets and conduit clips.

Advantages

The steel construction ensures consistent strength and durability in standard building environments. The simple, hammer-driven installation requires minimal tools and time, allowing quick anchoring in solid masonry and concrete. Supplied as a 100-piece pack, it supports multiple installations without frequent repurchasing and helps streamline on-site workflow. The compact geometry and defined length make positioning predictable for common installation depths.

Suitable for

• Securing rails and handrail supports to masonry or concrete
• Mounting metal brackets and light fixtures
• Fixing conduit clips and cable trays in solid substrates
• Temporary and permanent attachments where a mechanical anchor is preferred

Key specifications

• Material: steel (S variant)
• Nominal diameter: 6 mm
• Total length: 60 mm with effective anchoring length 30 mm
• Package quantity: 100 pieces
• Intended substrate: solid masonry and concrete
• Installation method: hammer-driven mechanical anchoring

How to use

Drill a hole in the masonry or concrete using a drill bit matching the anchor diameter, clean the hole of dust and debris, then insert the nail anchor flush with the fixture. Position the fixture and drive the nail with a hammer until the anchor engages and secures the part. Verify the anchor is seated to the required depth and the fixture is held firmly. Follow any project-specific torque or load recommendations for attached components and avoid overdriving which could deform the anchor.

Recommendations

Use in solid substrates only; do not use in hollow or crumbling materials. Select a drill bit of correct diameter, remove dust from drilled holes, and verify spacing and edge distances according to structural requirements. For safety, wear eye protection while drilling and hammering, and consult relevant load tables if anchoring critical or heavy items.
