Antena DeLOCK 89583 tipo N 3 dBi

Antena DeLOCK 89583 tipo N 3 dBi
Antena DeLOCK 89583 tipo N 3 dBi
44,13 €
PDF
PDF
Stock 1 Código 1739257 Modelo 89583 Garantía 3 años

Envíos y devoluciones

Entrega estimada lunes, 14 de diciembre
Te mantendremos informado a través de nuestro sistema de seguimiento detallado
Opciones de pago
Tarjeta bancariaVisaMastercardPayPalApple PayGoogle PayTransferencia bancaria

Haz una pregunta: el asistente IA responde al instante.

Descripción

The DeLOCK 89583 is an N-type antenna with 3 dBi gain, designed for operation at around 0.87 GHz (868 MHz band). It provides 50 Ω impedance and supports up to 100 W of input power. With a diameter of 22 cm and a lightweight construction (approx. 145 g), the antenna is suitable for both indoor and outdoor installation for wireless networking purposes.

Advantages

The antenna offers a simple, robust N-type connector design with a modest 3 dBi gain that improves signal reach while maintaining compact dimensions. Its 50 Ω impedance ensures compatibility with standard RF equipment, and the 100 W power handling makes it suitable for a variety of transmitters. The lightweight 145 g body and 22 cm diameter facilitate easy mounting and positioning.

Suitable for

Key specifications

How to use

Mount the antenna using appropriate brackets or fixtures for indoor or outdoor installation, ensuring the N-type connector is securely attached to the corresponding cable or device. Aim for clear line-of-sight where possible to optimize coverage in the 868 MHz band. Verify that connected equipment is configured for 50 Ω systems and does not exceed the antenna's 100 W maximum input power.

Recommendations

For best performance, place the antenna clear of large metallic obstructions and at an elevated position when possible. Use quality coaxial cable and connectors rated for 50 Ω to minimize signal loss and check local regulations for allowable transmission power in the 868 MHz band.

Aspectos destacados
  • Private and industrial wireless links in the 868 MHz band
  • Indoor and outdoor IoT gateways and sensors
  • RF testing and development where an N-type connector is required
  • Antenna type: N-type
  • Gain: 3 dBi
  • Frequency band: 0.87 GHz (868 MHz band)
  • Impedance: 50 Ω
  • Maximum input power: 100 W
  • Diameter: 22 cm
  • Weight: 0.145 kg
  • Brand: DELOCK, MPN: 89583, EAN: 4043619895830

Especificaciones

Especificaciones
Ancho del haz horizontal
360 °
Ancho del haz vertical
60 °
Banda de frecuencia
0.87
Código del Sistema Armonizado (HS)
85177100
Diámetro
220 mm
Ganancia de antena (máx.)
3 dBi
Impedancia
50 Ω
Peso
0.145 kg
Potencia admisible
100 W
Relación de onda estacionaria de voltaje (VSWR)
1.5
Tipo de conector de antena
Tipo N
