Bachmann BN0500 Local Metered 1U 19 Pulgadas PDU de aluminio, 6x C13 + 2x C19, CEE 16A, protección contra sobretensiones, 3m

For rack power distribution that demands precision and resilience, the Bachmann BN0500 Local Metered PDU stands apart with its integrated 3-digit LED display and built-in Type 3 surge protection. Unlike basic power strips, this 1U aluminium unit provides real-time monitoring of current, voltage, power, and energy directly at the rack, ensuring you always know exactly how your equipment is performing. The robust CEE 16A input and eight mixed outlets make it a versatile backbone for dense IT environments.

Highlights

• Local metered PDU with 3-digit LED display for current, voltage, power, and energy
• Integrated Type 3 surge protection device (SPD) safeguards connected equipment
• 8 outlets: 6x IEC C13 and 2x IEC C19, ideal for mixed server and network gear
• 1U 19-inch rack mount design in anodized aluminium for durability and efficient use of space
• 3m H05VV-F 3G2.5mm² cable with CEE 16A (IEC 60309) blue plug for secure high-current input

In daily use

Mount the BN0500 horizontally in a standard 19-inch rack and connect it to a 230V CEE 16A supply. The front-facing LED display cycles through electrical parameters, allowing quick checks without additional tools. The mix of C13 and C19 outlets accommodates everything from switches and routers to high-power servers and blade enclosures. Surge protection adds an extra layer of defense against transient voltage spikes, reducing the risk of downtime and hardware damage.

Full specifications

• Product type: Rack Power Distribution Unit (PDU)
• PDU type: Metered
• Mounting: 1U 19-inch rack mount
• Input: CEE 16A (IEC 60309) blue plug, 230V, 50/60 Hz
• Output: 6x IEC C13, 2x IEC C19
• Max current: 16A
• Max power: 3680W
• Surge protection: Type 3 SPD
• Cable: 3m H05VV-F 3G2.5mm²
• Housing: Anodized aluminium
• Operating temperature: 0 - 45 °C
• Protection class: IP20
• Certifications: CE, RoHS
• Colour: Silver/Black

Final note

With its local metering and surge protection, the BN0500 ensures your critical infrastructure stays informed and protected, making it a smart choice for any professional rack environment.
