Bopla BA-S 140806 F Bocube Carcasa de aluminio, aluminio, gris grafito (RAL 7024), 159 x 86 x 60 mm, IP66/IP67 00163124

The Bopla BA-S 140806 F Bocube Alu enclosure offers a hinged lid with quick-release fasteners and a recessed surface for membrane keypads, making it a practical choice for industrial electronics that require frequent access. Its graphite grey aluminium body (RAL 7024) measures 159 x 86 x 60 mm and provides a balance of durability and lightweight construction.

Highlights

• Hinged lid with integrated quick-release fasteners for convenient opening
• Recessed lid area suitable for membrane keypads or overlays
• Aluminium housing in graphite grey (RAL 7024)
• External dimensions: 159 mm length, 86 mm width, 60 mm height
• Protection class IP66/IP67 (dust-tight, protected against strong water jets and temporary immersion)
• Operating temperature range: -35 °C to +100 °C
• Seal material: PUR (polyurethane) with flammability rating UL 94 V-0
• Mounting options: wall mounting or desktop placement

Full specifications

• Product type: Universal enclosure
• Enclosure series: Bocube Alu
• Material: Aluminium
• Colour: Graphite grey (RAL 7024)
• External dimensions (L x W x H): 159 x 86 x 60 mm
• Protection class: IP66 / IP67
• Lid type: Hinged with quick-release fasteners
• Seal material: PUR (polyurethane)
• Seal flammability rating: UL 94 V-0
• Operating temperature range: -35 °C to +100 °C
• Mounting options: Wall mounting, desktop
• Application areas: Industrial electronics, control systems, measurement technology, IoT devices

Final note

The Bocube Alu series combines a robust aluminium housing with a user-friendly hinged design, suitable for applications where both protection and accessibility are important.
