BOPLA carcasa universal de aluminio gris plata (RAL 7001) 175 x 80 x 57 A 115 01115000.MT1

IP66-rated universal enclosure in silver-grey powder-coated aluminium, with external dimensions 175 x 80 x 57 mm. The robust AlSi 12 housing is built for industrial electronics, control systems, and measurement technology.

Overview

The BOPLA 01115000.MT1 is a two-part enclosure (base and lid) made from aluminium AlSi 12 with a powder-coated silver-grey finish (RAL 7001). It offers protection class IP66 and impact resistance IK08, making it suitable for demanding environments. The lid is fastened with captive stainless steel screws and sealed with a neoprene gasket. Internal mounting bosses allow secure installation of PCBs and components. Operating temperature range: -40 °C to +100 °C.

What stands out

• High protection: IP66 and IK08
• Durable aluminium construction with powder coating
• Neoprene gasket for reliable sealing
• Captive stainless steel lid screws
• Internal mounting bosses for easy assembly

Technical details

• External dimensions: 175 mm (L) x 80 mm (W) x 57 mm (H)
• Material: Aluminium AlSi 12
• Colour: Silver-grey (RAL 7001)
• Protection class: IP66
• Impact resistance: IK08
• Wall thickness: approx. 2.5 mm
• Operating temperature: -40 °C to +100 °C
• Lid fastening: captive stainless steel screws
• Gasket: neoprene
• Surface finish: powder-coated

Our verdict

A solid, weatherproof enclosure for industrial applications where reliability and protection are critical.
