Bopla BoLink BL 704025 WL2 DO-9005 Carcasa universal, policarbonato, negro RAL 9005, 71,1 x 43,2 x 26 mm, IP65, IK07, UL 94 V-0 16174565.HMT1

Electronic components need a robust, weather-resistant housing that protects them from dust, water, and mechanical impact. The Bopla BoLink BL 704025 WL2 DO-9005 universal enclosure provides a secure, durable solution for housing PCBs and other sensitive electronics in demanding environments. Made from polycarbonate in black (RAL 9005), it offers a compact yet spacious interior with integrated PCB mounting bosses for easy assembly.

Who is it for

This enclosure is ideal for electronics designers, system integrators, and manufacturers who require a reliable, off-the-shelf housing for control units, sensors, IoT devices, or industrial electronics. It is suitable for both indoor and outdoor applications where protection against the elements is critical.

Main features

• Material: Polycarbonate, black (RAL 9005)
• External dimensions: 71.1 x 43.2 x 26.0 mm
• Protection class: IP65 (dust-tight and protected against water jets)
• Impact resistance: IK07
• Flammability rating: UL 94 V-0
• Lid fastening: Screws
• Gasket material: Polyurethane (PUR)
• Operating temperature range: -40 to +80 °C
• Mounting type: Wall/surface mount
• Internal mounting options: PCB mounting bosses
• UV resistant and halogen-free

Specifications

• Series: BoLink
• Product type: Universal enclosure
• Material: Polycarbonate
• Colour: Black (RAL 9005)
• External length: 71.1 mm
• External width: 43.2 mm
• External height: 26.0 mm
• Protection class: IP65
• Impact resistance: IK07
• Flammability rating: UL 94 V-0
• Lid fastening: Screws
• Gasket material: Polyurethane (PUR)
• Operating temperature range: -40 to +80 °C
• Mounting type: Wall/surface mount
• Internal mounting options: PCB mounting bosses
• UV resistance: Yes
• Halogen-free: Yes

Tips

When selecting an enclosure, ensure that the internal dimensions accommodate your PCB and any connectors. The IP65 rating makes this enclosure suitable for outdoor use, but avoid prolonged submersion. Use the PCB mounting bosses to securely fasten your board without additional hardware.
