BOPLA carcasa universal aluminio gris plata (RAL 7001) 260 x 160 x 91 A 130 01130000.MT1

Industrial electronics often need a robust housing that protects sensitive components from dust, moisture, and mechanical impact. This BOPLA universal enclosure provides a durable aluminium body with a screw-on lid, suitable for a wide range of applications in measurement, control, and automation.

Who is it for

Engineers and technicians who build custom electronic devices for industrial environments will appreciate the solid construction and generous internal space. The enclosure is designed for wall mounting and includes internal bosses for mounting PCBs or plates.

Main features

• Material: Aluminium, powder-coated silver grey (RAL 7001)
• External dimensions: 260 mm length, 160 mm width, 91 mm height
• Screw-on lid with 8 stainless steel screws and silicone gasket
• Internal mounting bosses for PCBs or plates
• Wall mounting capability

Specifications

• Enclosure type: Universal enclosure
• Material: Aluminium
• Colour: Silver grey (RAL 7001)
• External length: 260 mm
• External width: 160 mm
• External height: 91 mm
• Protection class: IP66
• Impact resistance: IK08
• Operating temperature range: -40 °C to +100 °C
• Lid type: Screw-on lid
• Lid screw material: Stainless steel
• Number of lid screws: 8
• Gasket material: Silicone
• Surface finish: Powder-coated
• Internal mounting features: Mounting bosses for PCBs/plates
• Wall mounting capability: Yes

Tips

When selecting an enclosure, consider the environmental conditions and the required internal space for your electronics. The IP66 rating ensures protection against dust and powerful water jets, making it suitable for outdoor or washdown areas.
