Conector de red tipo F Bachmann 910.270

H05VV-F 3G 1.0 mm² flexible cable assembled in a compact plastic connector with integrated strain relief. The small unbreakable construction is designed for reliable low-voltage power connections in portable appliances and household devices where a thin, flexible lead is required.

Advantages

The assembly combines H05VV-F 3G 1.0 mm² cable with a sturdy plastic housing that resists impacts and prevents breakage at the entry point. Integrated strain relief reduces mechanical stress on conductors, extending service life and maintaining electrical continuity. Compact dimensions make it suitable for installations with limited space.

Key specifications

• Cable type: H05VV-F 3G 1.0 mm²
• Conductor configuration: 3 cores (live, neutral, earth)
• Construction: compact plastic connector with strain relief
• Use case: flexible power lead for portable appliances and household devices

How to use

Strip the cable ends according to connector instructions, insert conductors into the corresponding terminals and secure them with the provided screws or clamps. Ensure the strain relief grips the sheath to prevent movement of the conductors. Verify tight connections and test the assembly before regular use.

Recommendations

Use the assembly only within the cable's rated voltage and current limits and in dry or appropriately protected environments. If the sheath or connector shows damage, replace the assembly to avoid electrical hazards.
