Eaton DILM9-10 Contactor de potencia, 3 polos + 1NO, bobina 230V AC 50Hz / 240V AC 60Hz, 9A AC-3, 4kW, carril DIN

The Eaton DILM9-10 power contactor delivers reliable switching for three-phase motors up to 4 kW at 400 V AC-3. Its robust 3-pole main circuit with a built-in 1NO auxiliary contact ensures dependable control in industrial environments, while the dual-rated coil accepts 230 V AC at 50 Hz or 240 V AC at 60 Hz for flexible integration.

Advantages

Engineered for high electrical and mechanical endurance, this contactor offers 1.5 million electrical operations under AC-3 load and 10 million mechanical cycles. Screw terminals provide secure, maintenance-friendly connections, and the IP20 housing protects against accidental contact. Compliance with IEC/EN 60947-4-1 and VDE 0660 guarantees performance and safety.

Suitable for

• Motor starting and control in industrial machinery
• Heating, ventilation, and air conditioning (HVAC) systems
• Pump and compressor applications
• Conveyor and material handling equipment
• General switching of resistive and inductive loads up to 22 A AC-1

Key specifications

• 3 main poles, 3 NO contacts, rated 9 A at AC-3 (400 V)
• 1 built-in auxiliary contact, 1 NO
• Coil voltage: 230 V AC 50 Hz / 240 V AC 60 Hz
• Rated operational voltage up to 690 V AC
• Rated impulse withstand voltage: 6 kV
• Mounting: DIN rail or screw fixing
• Operating temperature: -25 °C to +60 °C
• Short-circuit protection: 16 A gG/gL fuse for main circuit, 10 A for auxiliary

Recommendations

For optimal performance, pair with Eaton PKZM0 motor-protective circuit breakers and use appropriate ferrules on screw terminals. Ensure coil voltage matches your control circuit to avoid premature failure.
