EFB-Elektronik Adaptador coaxial BNC hembra-hembra 50 Ohm (52522.1V2)

The EFB-Elektronik 52522.1V2 is a high-quality 50 Ohm BNC female-to-female coaxial adapter, designed for reliable signal transmission in RF and video applications. Manufactured by EFB-Elektronik, this adapter features gold-plated contacts and a nickel-plated brass housing for excellent conductivity and durability. It supports frequencies from DC to 4 GHz with low VSWR, making it ideal for professional and industrial use.

Advantages

This adapter ensures minimal signal loss and robust performance in demanding environments. Its straight configuration allows for easy inline connections, while the PTFE insulation provides stable impedance and high voltage resistance. With a durability of 500 mating cycles, it offers long-lasting reliability.

Suitable for

• RF and coaxial cable systems
• Video surveillance and CCTV installations
• Telecommunications and data networks
• Test and measurement equipment
• Broadcast and audio/video applications

Key specifications

• Connector Type A: BNC Female
• Connector Type B: BNC Female
• Impedance: 50 Ohm
• Gender: Female-Female
• Configuration: Straight
• Housing Material: Nickel-plated Brass
• Contact Plating: Gold-plated
• Insulation Material: PTFE (Teflon)
• Frequency Range: DC to 4 GHz
• Voltage Rating: 500 V (RMS)
• Dielectric Withstanding Voltage: 1500 V (RMS)
• Insulation Resistance: ≥ 5000 MΩ
• Contact Resistance (Center): ≤ 1.5 mΩ
• Contact Resistance (Outer): ≤ 1.0 mΩ
• VSWR: ≤ 1.3:1 @ 0-4 GHz
• Operating Temperature: -55°C to +85°C
• Durability: 500 mating cycles
• RoHS Compliant: Yes
• Standard: MIL-STD-348B (Interface)

Recommendations

For optimal performance, use with 50 Ohm BNC cables and connectors. Ensure proper mating and avoid exceeding the specified voltage and frequency limits. This adapter is a reliable choice for both permanent installations and temporary setups.
